Dengan pelbagai jenis tiub yang terdapat di pasaran, pengkategorian menjadi sukar. Aloi 20 tiub adalah salah satu daripada banyak tiub aloi. Ia terdiri daripada nikel, kromium dan besi. Tiub aloi 20 ERW pada mulanya dibangunkan untuk digunakan dalam persekitaran dengan pendedahan asid sulfurik terutamanya dalam kilang pulpa dan kertas. Kemudian, disebabkan sifat rintangan kakisan tiub Alloy 20, lebar jalurnya telah dikembangkan untuk disesuaikan dengan industri petrokimia, penjanaan kuasa dan kimia.

Tubos de aleación 20

Jadual Dimensi 20 Tiub Aloi

Ketebalan Nominal (dalam) MM	Saiz Paip (dalam)	Kawasan Melintang (Dalam 2) MM2			Diameter (dalam) MM		Kelantangan (kaki3/kaki)	Bilangan Benang setiap inci Skru	Berat badan		Panjang Paip (kaki setiap persegi.0 kaki permukaan)
dalaman	Luaran	Keluli	dalaman	Luaran	(kg/m)	(lbs/ft)	permukaan dalaman (kaki)	Permukaan Luaran (kaki)
0.007	1/8	0.006	0.013	0.007	0.027	0.0405	0.00004	27	0.036	0.024	14.020	9.043
0.009	¼	0.010	0.023	0.013	0.036	0.0540	0.00007	18	0.063	0.042	10.049	7.007
0.009	3/8	0.019	0.036	0.017	0.049	0.0675	0.00013	18	0.084	0.057	7.075	5.066
0.011	½	0.030	0.055	0.025	0.062	0.0840	0.00021	14	1.026	0.085	6.014	4.055
0.011	¾	0.053	0.087	0.033	0.082	1.0050	0.00037	14	1.068	1.013	4.064	3.064
0.013	1	0.086	1.036	0.049	1.005	1.0315	0.00060	11 ½	2.050	1.068	3.064	2.090
0.014	1 ¼	1.050	2.016	0.067	1.038	1.0660	0.00104	11 ½	3.038	2.027	2.077	2.030
0.015	1 ½	2.004	2.084	0.080	1.061	1.0900	0.00141	11 ½	4.004	2.072	2.037	2.001
0.015	2	3.036	4.043	1.008	2.007	2.0375	0.00233	11 ½	5.043	3.065	1.085	1.061
0.020	2 ½	4.079	6.049	1.070	2.047	2.0875	0.00333	8	8.062	5.079	1.055	1.033
0.022	3	7.039	9.062	2.023	3.007	3.0500	0.00513	8	11.027	7.058	1.025	1.009
0.023	3 ½	9.089	12.056	2.068	3.055	4.0000	0.00687	8	13.056	9.011	1.008	0.095
0.024	4	12.073	15.090	3.017	4.003	4.0500	0.00884	8	16.006	10.079	0.095	0.085
0.026	5	20.000	24.030	4.030	5.005	5.0563	0.01389	8	21.074	14.061	0.076	0.069
0.028	6	28.089	34.047	5.058	6.007	6.0625	0.02006	8	28.023	18.097	0.063	0.058
0.032	8	50.002	58.042	8.040	7.098	8.0625	0.03552	8	42.049	28.055	0.048	0.044
0.037	10	78.085	90.076	11.090	10.002	10.0750	0.05476	8	60.024	40.048	0.038	0.036
0.041	12	111.090	127.064	15.074	11.094	12.0750	0.07763	8	79.077	53.060	0.032	0.030
0.044	14	135.030	153.094	18.064	13.013	14.0000	0.09354	8	93.075	63.000	0.028	0.027
0.050	16	176.070	201.005	24.035	15.000	16.0000	1.02230	8	116.008	78.000	0.025	0.024
0.056	18	224.000	254.085	30.085	16.088	18.0000	1.05550	8	156.026	105.000	0.023	0.021
0.059	20	278.000	314.015	36.015	18.081	20.0000	1.09260	8	183.005	123.000	0.020	0.019
0.069	24	402.010	452.040	50.030	22.063	24.0000	2.07930	8	254.048	171.000	0.017	0.016
