Sekiranya anda mencariPaip keluli tahan karat berkualiti tinggi SS304, GNEE boleh membekalkan paiplancar dan dikimpalDalam saiz standard dengan panjang yang disesuaikan, kualiti yang disahkan dan rintangan kakisan yang sangat baik. Paip SS304 kami sesuai untukaplikasi perindustrian, kimia, makanan dan pembinaan, di mana prestasi, kebersihan dan ketahanan adalah kritikal.
Apakah saiz paip SS304 yang paling biasa?
Paip SS304 terutamanya tersedia dalam saiz1/2 "hingga 6" NPS, dengan ketebalan dinding dari1.65mm hingga 7.11mm.
Saiz paip SS304 standard berbeza -beza bergantung kepada jenis:
Paip lancar: Diameter dalaman nominal1/2 "hingga 16"
Rintangan Kimpalan Pipa (ERW):1/2 "hingga 24"
Pipa Dikimpal Elektrofusi (EFW):6 "hingga 100"
Ketebalan dinding berbeza mengikut kelas ketebalan (sch 5, sch 10, sch 40, sch 80 dan sch xxs), dan saiz boleh didapati diunit imperial (inci) dan metrik (milimeter)untuk diameter luar.
Saiz paip keluli tahan karat 304
304 Jadual 40 dimensi paip
| Saiz paip (dalam) | Diameter luaran (IN) | Diameter dalaman (dalam) | Ketebalan luaran nominal (dalam) | Ketebalan dalaman nominal (dalam) | Kawasan keratan rentas (in²) | Panjang paip (kaki per kaki permukaan) | VOLUME (ft³/ft) | Berat (lb/ft) | Berat (kg/m) | Bilangan benang per inci |
|---|---|---|---|---|---|---|---|---|---|---|
| 1/8 | 0.405 | 0.27 | 0.07 | 0.13 | 0.06 | 0.07 | 9.43 | 14.20 | 0.24 | 0.36 |
| 1/4 | 0.540 | 0.36 | 0.09 | 0.23 | 0.10 | 0.13 | 7.07 | 10.49 | 0.42 | 0.63 |
| 3/8 | 0.675 | 0.49 | 0.09 | 0.36 | 0.19 | 0.17 | 5.66 | 7.75 | 0.57 | 0.84 |
| 1/2 | 0.840 | 0.62 | 0.11 | 0.55 | 0.30 | 0.25 | 4.55 | 6.14 | 0.85 | 1.26 |
| 3/4 | 1.050 | 0.82 | 0.11 | 0.87 | 0.53 | 0.33 | 3.64 | 4.64 | 1.13 | 1.68 |
| 1 | 1.315 | 1.05 | 0.13 | 1.36 | 0.86 | 0.49 | 2.90 | 3.64 | 1.68 | 2.50 |
| 1 1/4 | 1.660 | 1.38 | 0.14 | 2.16 | 1.50 | 0.67 | 2.30 | 2.77 | 2.27 | 3.38 |
| 1 1/2 | 1.900 | 1.61 | 0.15 | 2.84 | 2.04 | 0.80 | 2.01 | 2.37 | 2.72 | 4.04 |
| 2 | 2.375 | 2.07 | 0.15 | 4.43 | 3.36 | 1.08 | 1.61 | 1.85 | 3.65 | 5.43 |
| 2 1/2 | 2.875 | 2.47 | 0.20 | 6.49 | 4.79 | 1.70 | 1.33 | 1.55 | 5.79 | 8.62 |
| 3 | 3.500 | 3.07 | 0.22 | 9.62 | 7.39 | 2.23 | 1.09 | 1.25 | 7.58 | 11.27 |
| 3 1/2 | 4.000 | 3.55 | 0.23 | 12.56 | 9.89 | 2.68 | 0.95 | 1.08 | 9.11 | 13.56 |
| 4 | 4.500 | 4.03 | 0.24 | 15.90 | 12.73 | 3.17 | 0.85 | 0.95 | 10.79 | 16.06 |
| 5 | 5.563 | 5.05 | 0.26 | 24.30 | 20.00 | 4.30 | 0.69 | 0.76 | 14.61 | 21.74 |
| 6 | 6.625 | 6.07 | 0.28 | 34.47 | 28.89 | 5.58 | 0.58 | 0.63 | 18.97 | 28.23 |
| 8 | 8.625 | 7.98 | 0.32 | 58.42 | 50.02 | 8.40 | 0.44 | 0.48 | 28.77 | 42.82 |
304 Berat Paip Kimpalan Keluli Tahan Karat Per Kaki
| Saiz nominal | Diameter luaran (IN) | Diameter luaran (mm) | Ketebalan dinding (dalam) | Ketebalan dinding (mm) | Berat (lb/ft) | Berat (kg/m) |
|---|---|---|---|---|---|---|
| 1/2 "DN15 | 0.84 | 21.3 | 0.109 | 2.77 | 0.85 | 1.27 |
| 3/4 "DN20 | 1.05 | 26.7 | 0.113 | 2.87 | 1.14 | 1.7 |
| 1 "DN25 | 1.32 | 33.4 | 0.133 | 3.38 | 1.69 | 2.52 |
| 1 1/4 "DN32 | 1.66 | 42.2 | 0.14 | 3.56 | 2.29 | 3.41 |
| 1 1/2 "DN40 | 1.9 | 48.3 | 0.145 | 3.68 | 2.74 | 4.08 |
| 2 "DN50 | 2.375 | 60.3 | 0.154 | 3.91 | 3.68 | 5.47 |
| 2 1/2 "DN65 | 2.875 | 73.0 | 0.203 | 5.16 | 5.84 | 8.69 |
| 3 "DN80 | 3.5 | 88.9 | 0.216 | 5.49 | 7.64 | 11.36 |
| 3 1/2 ″ | 4.0 | 101.6 | 0.226 | 5.74 | 9.18 | 13.66 |
| 4 "DN100 | 4.5 | 114.3 | 0.237 | 6.02 | 10.87 | 16.18 |
| 5 "DN125 | 5.563 | 141.3 | 0.258 | 6.55 | 14.72 | 21.91 |
| 6 "DN150 | 6.625 | 168.3 | 0.28 | 7.11 | 19.11 | 28.44 |
| 8 "DN200 | 8.625 | 219.1 | 0.322 | 8.18 | 28.77 | 42.82 |
| 10 "DN250 | 10.75 | 273.1 | 0.365 | 9.27 | 40.79 | 60.7 |
| 12 "DN300 | 12.75 | 323.9 | 0.375 | 9.53 | 49.91 | 74.28 |
Penarafan tekanan paip lancar TP304
| Saiz paip (dalam) | Jadual | Suhu (darjah f) |
|---|---|---|
| 1″ | 40 | 3048/2629/2362/1171/2019/1924/1867/1824/1810 |
| 1″ | 80 | 4213/3634/3265/3002/2791/2659/2580/2528/2501 |
| 1″ | 160 | 6140/5296/4759/4375/4068/3876/3761/3684/3646 |
| 1 1/2 ″ | 40 | 2257/1947/1750/1608/1496/1425/1383/1354/1340 |
| 1 1/2 ″ | 80 | 3182/2744/2266/2267/2108/289/1949/1909/1889 |
| 1 1/2 ″ | 160 | 4619/3984/3580/3291/3060/2916/2829/2772/2743 |
| 2″ | 40 | 1902/1640/1474/1355/1260/1201/1165/1141/1129 |
| 2″ | 80 | 2747/2369/1129/1957/1820/1734/1682/1648/1631 |
| 2″ | 160 | 4499/3880/3486/3205/2980/2840/2755/2699/2671 |
| 3″ | 40 | 1806/1558/11 1400/1287/1196/1140/1106/1084/1072 |
| 3″ | 80 | 2553/2202/779/1819/1691/1612/1564/1532/1516 |
| 3″ | 160 | 3840/3312/2976/2736/2544/2324/2352/2304/2280 |
